Overview

Keeping your home comfortable and warm is a high priority-but it doesn't have to come at a high cost. Whether you heat by baseboard, panel radiators, hydro-air systems or radiant flooring, our advanced heating systems will provide many years of exceptional comfort and savings. A conventional boiler heats and circulates water at only one temperature; typically 170 to 180 degrees until the thermostat signals it to stop. A Buderus boiler, especially when paired with the Logamatic control, eliminates these room temperature swings by adjusting the boiler water temperature to the current conditions, saving fuel while keeping you warm and comfortable. Sections are assembled with beveled, surface profiled push nipples for long, trouble free watertight operation. Special sealing compounds provide a gas tight seal for safe and efficient operation.

Burner Information

• For a chimney vent application use one of the following burner kits: Becket AFG (part number 7738004857), Riello F-5 (part number 7738004842), or Carlin EZ-1 (part number 7738004845). BTU: 126,000 BTU input - 109,000 BTU heating capacity
• For a direct vent application use one of the following burner kits: Beckett NX (part number 7738004848), Riello BF3 (part number 7738004851), or Carlin EZ-1 (part number 7738004854) BTU: 112,000 BTU input - 98,000 BTU heating capacity

Features

• Boilers can be set up to be atmospheric vent or direct vent, depending on the burner chosen
• Designed to operate at any return water temperature
• Full swing burner door can be hinged on either side
• No refractory parts for reduced maintenance
• Boiler is fully serviced and cleaned from the front
• Cast iron breaching for long life
• Thermostream design increases efficiency and reliability
• High efficiency through full three pass boiler design
• Includes standard B-Kit consisting of: burner mounting bolt set, 1-1/2 inch x 1-1/2 inch x 1/4 inch supply manifold, 1-1/4 inch x 3/4 inch BMI bushing, 1 inch BMI plug, 3/4 inch BMI street 90 elbow, 3/4 inch quarter turn boiler drain, 30 PSI relief valve, and tridicator.
• Rear tappings and flue connection
• Baffles and clips for adjusting stack temperatures
• Front access plugs for flushing the boilers interior
• Three inch thick thermal insulation
